3kw Hybrid Solar Inverter with put-in MPPT Control
3kw Hybrid Solar Inverter with put-in MPPT Control
3kw Hybrid Solar Inverter with put-in MPPT Control
3kw Hybrid Solar Inverter with put-in MPPT Control

3kw Hybrid Solar Inverter with put-in MPPT Control

This solar inverter is an important part of the solar power system. Solar energy can help to reduce the cost of electricity, contribute to a resilient electrical grid, create jobs and spur economic growth, generate back-up power for nighttime and outages

SYSTEM TYPE : Customized Off-Grid Solar System

PRODUCT ORIGIN : CHINA

SHIPPING : Support Express · Sea freight · Land freight · Air freight

PAYMENT : 50% deposit by T/T , 50% balance by T/T before shipment

Produt Details



Rekesun 3kw Solar Inverter Description

Rekesun  provide Pure Sine Wave 1000W-6000W Off Grid Solar Inverter based on 12V/24V/48V/96V DC input,our off grid inverter have some advantages:

*Built-in MPPT solar charge controller

*Input & output fully isolation.

*Adoption of advanced SPWM technology, pure sine wave output.

*Dynamic current loop control technology to ensure inverter reliable operation

*LED indicators for input voltage range, load power range, normal output&failure state

*Wide working temperature range(industrial level)

*Continuous operation at full power

*Overload and short circuit protection

*Smart battery charger  for optimized battery

1-3kw:

MODEL

LK1KW

LK2KW

LK3KW

Rated power

1000W

2000W

3000W

INPUT

Voltage

    220VAC

Voltage Range

170-280V AC

Frequency Range

       50Hz/60Hz (Auto sensing)

OUTPUT

AC Voltage

220VAC

Efficiency(Peak)

97%

Wave form

Pure sine wave

BATTERY&AC CHARGER

Battery Voltage

12VDC

24VDC

24VDC

Floating charge voltage

14VDC

27VDC

27VDC

Overcharge Protection

16VDC

33VDC

33VDC

Maximum charge current

20A

40A

40A

SOLAR CHARGER

MAX.PV Array Power

1000W

2000W

4000W

MPPT Range Operating Voltage

120~450VDC

Maximum Charging Current

30A

60A

80A

Maximum Efficiency

97%

PHYSICAL

Dimension.D*W*H(mm)

420*313*117

Maximum Charging Current

30A

60A

80A

Net Weight (kgs)

8KG

15KG

18KG
